Thông số kỹ thuật
| Max Working Height |
7.79m |
|---|---|
| Max Platform Height |
5.79m |
| Platform Size (stowed) |
0.61m x 1.69m |
| Platform Size (extended) |
0.61m x 2.6m |
| Extension Deck Length |
0.91m |
| Overall Length |
1.91m |
| Overall Width |
0.77m |
| Stowed Height |
1.76m |
| Ground Clearance (stowed) |
76mm |
| Ground Clearance (elevated) |
15mm |
| Platform Capacity (SWL) |
250kg |
| Max Drive Height |
5.79m |
| Max Wind Speed |
12.5m/s |
| Max Drive Speed (stowed) |
2.4km/h |
| Max Drive Speed (elevated) |
0.8km/h |
| Raise/Lower Time |
30 / 44 seconds |
| Gradeability |
25% |
| Inside Turning Radius |
0m |
| Outside Turning Radius |
1.77m |
| Tyres |
323mm x 102mm non-marking solid rubber |
| Controls |
proportional |
| Drive System |
2 wheel electric drive |
| Power Source |
24V DC battery electric |
| Charger |
90 – 240V, 25amp |
| Weight |
1,581kg |
